 SR Departmental Saloon ' Caroline'

Non Sound & Sound Only 21Pin Decoders,.. See options when ordering:

***IMPORTANT: All sound decoders we recommend be sent Insured special delivery***

Function List  (We suggest you print this off, as you might need it later.).

IMPORTANT:

To alter the overall sounds use CV63 ( 0 to 192 )

To alter individual sounds listed below, you must set the following Indexing CVs (CV31 to 16 and CV32 to 1)

Function Key Layout for LOK PILOT  (Non Sound) V5 .

F0 Directional Lights.

F8 Step Light.

F12 Interior Lights.

F13 Top Flood Lights.

F14 Cab/Lighting.

F19 Push-Pull Mode: Saloon in No1 End of Loco.

F20 Push-Pull Mode: Saloon in No2 End of Loco.

F22 Interior Lights.

F27 Top Flood Lights.

F28 Step Lights.

...................................................................................................................................................................................................................

Function Key Layout for LOKSOUND V5 .

F0 Directional Lights.

F1 Motor Generator Set                                                    CV387=128
F2 Playable High Note Horn.                                            CV443=128
F3 Playable Low Note Horn.                                             CV435=128

F4 Buffering up (If moving() of Coupling.                       CV283=110

F5 Playable Active Brake Application (When moving)  CV291=128
F6 Drivers door slam.                                                        CV299=110
F7 Compressor.
F8 NOT USED
F9 Automatic Flange/Wheel Squeal.                                CV323=100
F10 Despatch Whistle.                                                       CV331=80,            CV459=128
F11 Guard to Driver Buzzer with optional reply.             CV339=128
F12 NOT USED.
F13 NOT USED.
F14 Cab/Lighting.                                                              CV427=128

F15 NOT USED.
F16 NOT USED.
F17 Front Wipers.                                                             CV387=128
F18 Speed Dependant, Flash Enabled Detonators.      CV395=128
F19 Push-Pull Mode: Saloon in No1 End of Loco.        CV427=128
F20 Push-Pull Mode: Saloon in No2 End of Loco.        CV427=128

F21 NOT USED.
F22 Interior Lights.
F23 & F24 NOT USED.
F25 RETB Request & Reply.                                            CV489=20
F26 NOT USED.

F27 Top Flood Lights.

F28 Step Lights.

F29 AWS Bell.                                                                   CV483=128

F30 AWS Bell.                                                                    CV491=128
